Intelligent Bubble Film Packaging Machine
YJP-90E Intelligent Bubble Film Packaging Machine
YJP-90E Intelligent Bubble Film Packaging Machine is the protective packaging model in the YJP series, designed for products that require cushioning during transportation.
Unlike YJP-40E, YJP-60E and YJP-70E, which focus on conventional bag packaging, YJP-90E uses bubble film to create a protective package around the product. Its three-servo control system integrates automatic feeding, bubble film forming, sealing and cutting into one continuous operation.
The supplied catalog specifies a packaging speed of 30–100 bags/min and supports multiple film materials including PP, CPP, PVC, PS, EVA, PET, PVDC+PVC and OPP/CPP
- Three-Servo Intelligent Control
- 30–100 Bags/Min
- Automatic Film Feeding
- Bubble Film Forming
- Automatic Sealing
- Automatic Cutting
- Protective Cushioning Packaging
- Multiple Film Material Compatibility
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | YJP-90E |
| Product Type | Bubble Film Packaging Machine |
| Package Length | 100–500 mm |
| Package Width | 35–200 mm |
| Package Height | 5–60 mm |
| Packaging Speed | 30–100 bags/min |
| Film Width | 90–450 mm |
| Film Type | PP, CPP, PVC, PS, EVA, PET, PVDC+PVC, OPP/CPP etc. |
| Power Supply | 220V 50Hz |
| Total Power | 4.1kW |
| Machine Weight | 260kg |
| Machine Size | 3640 × 960 × 1100 mm |
Details
YJP-90E Protective Bubble Film Packaging Machine
YJP-90E is the specialized protective-packaging model in the YJP series. Its purpose is different from standard bagging machines: instead of simply enclosing the product, it uses bubble film to provide cushioning protection during transportation.
Three-Servo Intelligent Control
The machine uses a three-servo control system to coordinate film feeding, positioning and packaging operations.
This helps maintain controlled material movement during continuous packaging.
Automatic Film Feeding
The packaging film is automatically fed into the packaging process, reducing repetitive manual handling.
Bubble Film Forming
The system forms the bubble-film packaging around the product before the sealing stage.
Automatic Sealing & Cutting
The machine integrates sealing and cutting into the same automated process, producing a finished protective package without requiring separate manual cutting.
Protective Packaging
Bubble-film packaging provides cushioning for products that may be vulnerable to impact, vibration or compression during logistics handling.
Flexible Film Compatibility
The product material identifies compatibility with multiple film materials:
- PP
- CPP
- PVC
- PS
- EVA
- PET
- PVDC+PVC
- OPP/CPP
High-Speed Protective Packaging
The machine supports 30–100 bags/min, making it suitable for continuous protective packaging operations.
Automation Integration
The product material states that the machine can be connected with conveyors and warehouse automation systems, allowing it to be incorporated into a broader fulfillment workflow.
Why Choose YJP-90E?
YJP-90E is the appropriate choice when the main requirement is:
- Product protection
- Bubble-film cushioning
- Fragile-product packaging
- Continuous protective packaging
- Automated feeding and sealing
Application
- Fragile e-commerce products
- Electronics packaging
- Consumer goods requiring cushioning
- Protective logistics packaging
- Industrial product protection
- Automated fulfillment packaging
FAQ
The YJP-90E is an intelligent bubble film packaging machine designed for e-commerce, logistics and industrial protective packaging applications.
The main difference is the packaging material and purpose. The YJP-90E uses bubble film to provide cushioning protection, while the YJP-40E, YJP-60E and YJP-70E focus on conventional bag-based packaging workflows.
The specified packaging speed is 30–100 bags per minute.
The specified package range is 100–500 mm in length, 35–200 mm in width and 5–60 mm in height.
The machine supports PP, CPP, PVC, PS, EVA, PET, PVDC+PVC, OPP/CPP and other listed film materials.
Yes. Automatic bubble-film feeding is integrated into the packaging process.
Yes. The system integrates sealing and cutting into the automated packaging workflow.
Yes. Bubble film provides cushioning protection and the machine is designed for applications where product protection is important during transportation.
Yes. The system uses a three-servo control architecture.
Yes. The product information states that the machine can be connected with conveyors and warehouse automation systems.
